Overview
GY-304EP-E is a small fast Ethernet POE switch, providing 5 electrical fast Ethernet ports. All the 5 ports support speed and duplex auto-negotication and auto MDI-MDIX function, plug an play. Port 1~4 support IEEE802.3af/at standard PoE power supply over Ethernet cable and provide 15W or 30W power per port. GY-304EP-E provides a switch button to extend the Ethernet transmission distance of 4 POE Ethernet ports up to 250m. All of these features make the product ideal for many applications such as video surveillance, WIFI coverage, intelligent building, and factory automation, etc.
※ Support Auto MDI-MDIX function
※ Wire speed performance
※ Support IEEE802.3x pause frame-based and backpressure flow control
※ Switch button for extending the Ethernet transmission distance up to 250m
※ Support IEEE802.3 af/IEEE802.3 at standard 15/30W PoE
※ Support 30W/port, total 120W POE power output
※ 42～56V DC power supply
